Ubiquiti Ubiquiti UniFi Switch 8 Managed Gigabit Ethernet (10/100/1000) Grijs Power over Ethernet (PoE)
Ubiquiti UniFi Switch 8 Managed Gigabit Ethernet (10/100/1000) Grijs Power over Ethernet (PoE) 99,-

Ubiquiti UniFi Switch 8 Managed Gigabit Ethernet (10/100/1000) Grijs Power over Ethernet (PoE)

€99,- €99,00
Op voorraad
EAN: 0810354026171
SKU: US-8
  • Op werkdagen voor 18 uur besteld? Morgen geleverd!
Informatie

Ubiquiti Networks UniFi Switch 8. Switch type: Managed. Type basis-switching RJ-45 Ethernet-poorten: Gigabit Ethernet (10/100/1000), Aantal basis-switching RJ-45 Ethernet-poorten: 8. Switchingcapaciteit: 16 Gbit/s. Netwerkstandaard: IEEE 802.1x,IEEE 802.3af. Netstekker: DC-in ingang. Power over Ethernet (PoE). Ophangsysteem voor aan de muur

The UniFi Switch 8-port models feature Gigabit Ethernet ports in a compact form factor. The switches are fully manageable, delivering robust performance and intelligent switching for your networks.

The US-8 is a PoE Powered 8-port gigabit switch with PoE Passthrough. Perfect for cleanly adding Ethernet ports where needed, with passthrough to keep your PoE device powered.

Non-Blocking Throughput
The new 8-port models feature Gigabit Ethernet ports in a compact form factor. For its total, non-blocking throughput, each UniFi Switch supports up to 8 Gbps.

Switching Capacity
The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss, with a switching capacity of 16 Gbps.

Seamless Integration
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.

Specificaties

Beheerfuncties

Switch type
Managed
Web-gebaseerd management


Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten
8
Type basis-switching RJ-45 Ethernet-poorten
Gigabit Ethernet (10/100/1000)
Netstekker
DC-in ingang

Netwerk

Netwerkstandaard
IEEE 802.1x,IEEE 802.3af
10G support

Port mirroring

Datastroombeheer

Broadcast stormbeheer

Spanning tree protocol

Auto-sensing

VLAN=ondersteuning


Data-uitwisseling

Switchingcapaciteit
16 Gbit/s
Throughput
8000 Mpps
Jumbo Frames ondersteuning


Design

Kleur van het product
Grijs
Materiaal behuizing
Staal
Reset button

LED-indicatoren
Activiteit, Link, Power over Ethernet (PoE), Snelheid
Ophangsysteem voor aan de muur

Certificering
ETSI300-019-1.4, CE, FCC, IC

Prestatie

Type processor

Frequentie van processor
400 MHz
Intern geheugen
256 MB

Energie

Spanning
48 V
Output current
1,25 A
Vermogensverbruik (max)
12 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)

Hoeveelheid Power over Ethernet (PoE) ports
1
Voltagebereik Power over Ethernet (PoE)
57 - 44 V
Vermogen per poort Power over Ethernet (PoE)
15,4 W
Totaal Power over Ethernet (PoE)-budget
60 W

Eisen aan de omgeving

Temperatuur, in bedrijf
-5 - 45 °C
Relatieve luchtvochtigheid, in bedrijf
5 - 95 procent

Gewicht en omvang

Breedte
148 mm
Diepte
99,5 mm
Hoogte
30,7 mm
Gewicht
432 g

Verpakking

Meegeleverde kabels
AC
Snelstartgids

Inclusief AC-adapter


Multimedia

Folder - leaflet
Gebruikershandleiding - manual pdf
